Kootenay Silver Inc. (TSXV: KTN) (the “Company” or “Kootenay”) is pleased to announce details of recently completed drill program and provides guidance for resource expansion potential along extensions of its 100% owned La Cigarra silver resource located in the Parral Silver District of Chihuahua State, Mexico.
The Company has designed a drill program (the “Program”) aimed at the dual purpose of resource expansion along the immediate extensions of the La Cigarra deposit (the “Resource”) and at outlining the scope of that potential. There are four target areas identified where the Company believes there is untested potential to increase the Resource by significant amounts (see table below). The plan would entail primarily exploration step out drilling of known mineralization and some infill drilling of the successful La Borracha program earlier this year.
The four areas Kootenay plans to target are the La Borracha high grade (the mineralized trend located 1,000 meters northwest from the northern boundary of the Resource), the La Borracha Connection (connecting La Borracha with the San Gregorio area of the Resource), Gap (a very under drilled area between the main San Gregorio and Las Carolinas zones that currently comprise the Resource) and the Carolinas Extension (the strike extension of the Resource to the southeast). Testing of these four areas would entail approximately 15,000 meters of drilling over 62 holes. This Program is considered for 2019.
Target Areas and Potential Silver Ounces
| Potential Silver Ounces | ||||||
|---|---|---|---|---|---|---|
| Zone | Holes / Meters | Target Area Tonnes | 60 gpt Silver (50% tonnage) | 60 gpt Silver (100% tonnage) | 85 gpt Silver (50% tonnage | 85 gpt Silver (100% tonnage) |
| GAP | 24 / 6,590 | 18,404,620 | 17,753,653 | 35,507,305 | 25,151,008 | 50,302,016 |
| Borracha High Grade | 10 / 1,830 | 8,625,760 | 8,320,669 | 16,641,338 | 11,787,614 | 23,575,228 |
| Borracha/SG Connector | 13 / 2,720 | 18,564,000 | 17,907,395 | 35,814,791 | 25,368,810 | 50,737,621 |
| Las Carolinas Extension | 15 / 3,530 | 18,732,480 | 18,069,916 | 36,139,833 | 25,599,048 | 51,198,096 |
| Total | 62 /14,670 | 64,326,860 | 62,051,633 | 124,103,267 | 87,906,481 | 175,812,961 |
These exploration Targets (“Targets”) are based on the interpretation and extrapolation of the known mineralized zones using all available data including drill intercepts, geologic surveys and surface sampling. There is no assurance that drilling the Targets will result in any increase in the current resource. Readers are cautioned that the potential quantity and grade is conceptual in nature, there has been insufficient exploration to define a mineral resource and it is uncertain if further exploration will result in the target being delineated as a mineral resource.
The Program was designed by modeling the known mineralization in existing drill intercepts and developing three dimensional mineralized domains or shapes utilizing 3D Leap Frog software (the “Software”). These domains were then extrapolated between wide spread drill holes outside the resource; along strike and down dip beyond existing drill holes forming the Targets. These Targets are the extrapolation from hard data of known drill hole intercepts or the resource itself and is further supported by surface mapping, sampling and geophysical surveys. The Software was then used to estimate a potential tonnage size for each Target. Grade ranges were then applied using the resource grade and a grade 25% lower than the resource to create a range for Target potential. A second lower range was then created by looking at tonnages at 50% of the speculated Target size.
The current Resource of 51. 5 million ounces of Measured and Indicated and 11.5 million ounces of Inferred is open along both strike directions and down dip (see Resource table further in news release). The 2018 drill program successfully established silver mineralization for 1000 meters to the northwest of the Resource (see news release dated April 11, 2018) and further indicated open ended mineralization to the southeast into the Carolinas Extension area (see news release July 12, 2018).
The La Cigarra Property is approximately 18,000 hectares and covers the northern 20-kilometer portion of a 40+ kilometer mineralized trend which has produced over half a billion ounces of silver in the San Francisco Del Oro and Santa Barbara mining district that in 2016 reported an estimated reserve of 200 million ounces of silver.
La Cigarra Resource Estimate
La Cigarra’s updated NI 43-101 resource estimate was completed by Allan Armitage, PhD, P. Geo. and Joe Campbell, B.Sc., P. Geo., of GeoVector Management Inc. Resource Statement for the La Cigarra silver project located in Chihuahua State, Mexico: Effective Date January 14, 2015. The resource estimate was constrained by a constrained pit shell utilizing a $22 /oz silver price and reported at a 35 g/t silver cut-off grade and considers metallurgical recoveries of 84% silver. A summary of the mineral resource estimate is listed below:
| Resource Category* | Tonnes | Grade | Contained Metal | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Ag (g/t) | Au (g/t) | Pb (%) | Zn (%) | Ag (oz) | Au (oz) | Pb (lbs) | Zn (lbs) | ||
Measured | 3,620,000 | 88.9 | 0.074 | 0.14 | 0.19 | 10,340,000 | 9,000 | 10,920,000 | 15,510,000 |
Indicated | 14,930,000 | 85.7 | 0.068 | 0.13 | 0.18 | 41,130,000 | 33,000 | 42,950,000 | 59,260,000 |
Meas + Ind | 18,540,000 | 86.3 | 0.069 | 0.13 | 0.18 | 51,470,000 | 41,000 | 53,870,000 | 74,770,000 |
Inferred | 4,450,000 | 80.0 | 0.058 | 0.13 | 0.16 | 11,460,000 | 8,000 | 12,680,000 | 15,610,000 |
Qualified Persons
The Kootenay technical information in this news release has been prepared in accordance with the Canadian regulatory requirements set out in National Instrument 43-101 (Standards of Disclosure for Mineral Projects) and reviewed and approved on behalf Kootenay by James McDonald, P.Geo, President, CEO & Director for Kootenay, a Qualified Person.
